KP80 Flake Ice Machine

  • Flake Ice Maker
  • Flake Ice Maker
  • Flake Ice Maker
Koller Flake Ice Machine Parameter:
Model Item KP80
Capacity (Tons/24hours) 8
Refrigerant R22/R404A
Compressor Brand Bitzer/ Copeland/ Bock
Cooling Way Water
Compressor Power (HP) 22.5
Motor Power (KW) 0.75
Circulating Water Pump (KW) 0.4
Cooling Water Pump (KW) 4
Cooling Fan Motor (KW) 1.5
Size Length (mm) 2400
Width (mm) 2200
Height (mm) 1850
Weight (Kg) 1900

Supply Power: 380V~420V, 50Hz/60Hz, 3P; 220~240V, 60Hz, 3P; 440V~480V, 60Hz, 3P
Standard Working Conditions: Input Water Temperature: 21℃;& Condensing Temperature: 40 ℃ Evaporating Temperature: -20 ℃
As the technology is rapidly developing, some of the above specifications can be changed without notice.
